Wall mounted standby-power changeover, with specification support from FW Power.
The lowest current rating in the CTI range shown here. It shares the same enclosure dimensions and weight as the CTI 100, 125 and 160; select by the electrical duty, not by cabinet size.
Price, lead time, available options and the final build specification are confirmed with your quotation.
The listed envelope and weight help you compare panels and plan space. Allow additional room for cable bends, termination access, doors and maintenance.
Final drawings and the ordered configuration take precedence when planning the installation.
Read our transfer switch specification guide| Manufacturer | FG Wilson |
|---|---|
| Model | CTI 63 |
| Rated current | 63 A |
| Panel type | Automatic transfer switch / load transfer panel |
| Mounting | Wall mounted |
| Height | 600 mm |
| Width | 400 mm |
| Depth | 200 mm |
| Weight | 19 kg |
| Cable entry | Top and bottom |
| IP54 enclosure | Optional; specify at enquiry |
| Voltage, frequency and poles | Confirm for the selected configuration |
| Fault duty and protection | Confirm against the installation design |
Published range data, subject to final configuration. No generator kVA equivalence is assumed.
The CTI 63 belongs to FG Wilson’s CTI load-transfer range. The controls monitor supply conditions, request a compatible generator start and manage transfer and return to mains according to the commissioned sequence.
The padlocking feature is available in manual operation mode.
Options depend on the selected model and current build specification. Confirm every required function in your quotation.
Confirm the supply voltage, phase and frequency, neutral and earthing arrangement, load duty, fault level, protection, cable capacity and generator-start interface.
A standard open-transition ATS does not provide uninterrupted power or generator paralleling. Tell us if the load requires UPS support or a different transfer arrangement.
Discuss panel supply, replacement of existing equipment or a wider generator and changeover proposal. We can review alternatives if this model or its configuration does not meet your requirements.
Share your site location, required date, quantity, supply details, generator controller and single-line diagram if available. State any environmental, access or monitoring requirements.
